Order Number: E4041
Data Rate: Adaptive, (Max) 2M
Addressing Method: Set by the main station software
Module Power Supply: Connected internally to the system
Protection Grade: IP20
Installation Method: DIN35 rail installation or hole drilling installation
Operating Temperature: -20℃ to +75℃
Output Channel: 4
Output Type: Current Type / Voltage Type
Resolution: 12 bits (16 bits represented, including the sign bit)
Output Range (Current): 4~20mA
Output Range (Voltage): 0~10V
Output Impedance: Voltage Output > 1KΩ, Current Output < 500Ω
Output Error: ±0.3% (Full Scale)
Output Rate: 1ms/Time Step
