Order Number: PP-150-24
● Full range AC input: 90~264VAC
● Protection types: Short circuit / Overload / Overvoltage / Overtemperature
● Mounting rail: TS-35/7.5 or 15
● Narrow width: 30mm
● 100% full load aging test
● High reliability
● 3-year warranty
● Compliant with IEC/EN/UL 62368-1
Input parameters
Voltage range: 90 - 264VAC, 127 - 370VDC
Frequency range: 47 - 63Hz
Efficiency (typical value): 89%
AC current (typical value): 2.8A/115VAC, 1.6A/230VAC
Inrush current (typical value): 30A/115VAC, 55A/230VAC (cold start)
Leakage current: <1mA/240VAC
Output parameters:
DC Voltage: 24V
Rated Current: 6.25A
Current Range: 0 - 6.25A
Rated Power: 150W
Ripple and Noise (Maximum): 120mVp-p
Voltage Adjustment Range: 24 - 28V
Voltage Accuracy: ±1%
Line Regulation: ±0.5%
Load Regulation: ±1%
Startup, Rise Time: 500ms, 50ms / 230VAC 500ms, 50ms / 115VAC
Hold Time (Typical): 30ms / 230VAC 7ms / 115VAC
Protection parameters:
Overload: 105% to 135% of rated output power
Protection mode: Constant current limit (output voltage > 50% Vo), otherwise hiccup, self-recovery after abnormal condition removed
Overvoltage: 29 to 33V
Protection mode: Shutdown, recovery after restart
Overtemperature:
Protection mode: Shutdown, recovery after restart
Environmental parameters:
Operating temperature and humidity: -20 to +70℃ (refer to "derating curve"), 20 to 90% RH, no condensation
Storage temperature and humidity: -40 to +85℃, 10 to 95% RH
Temperature coefficient: ±0.03%/℃ (0 to 50℃)
Vibration resistance: 10 to 500Hz, 2G for 10 minutes per cycle, each along X, Y, and Z axes
