Order Number: IES-1050-S
Electrical Port: 5xRJ45 (with shielding)
Power Interface: 1x3P plug-and-unplug terminal
Operating Current: 150mA at 12V under full load
Channel Number: 5
Transmission Rate: 10/100M (Maximum), Adaptive
Packet Forwarding Rate: 0.744Mpps
Backplane Bandwidth: 1Gbps
Connection Mode: Adaptive for Parallel Line/Crossed Line
Operating Voltage: 12~52VDC Flexible Power Supply
Protection Grade: IP50
Installation Method: DIN35 Rail Installation
Operating Temperature: -40℃~+85℃
Operating Humidity: 5%~90%
