Order Number: E8041
Data Rate: Adaptive, (Max) 2M
Addressing Method: Set by the main station software
Module Power Supply: Connected internally to the system
Protection Grade: IP20
Installation Method: DIN35 rail installation or hole drilling installation
Operating Temperature: -20℃ to +75℃
Input channel: 4
Resolution: 12 bits (16-bit representation, including sign)
Sensor type: PT100, Cu50
Temperature range: -200℃ to +850℃ (for PT sensor), -60℃ to +250℃ (for NI sensor)
Data output: 0.1℃ per digit
Sampling error: ±1℃ (full scale)
Sampling speed: 500ms per time
Software filtering: Configurable
