Order Number:IES-1080S-mini
Electrical port: 8xRJ45 (with shielding)
Power interface: 1x5-pin plug-and-unplug terminal
Operating current: 350mA at 12V under full load
Channel count: 8
Transmission rate: 10/100M (maximum), adaptive
Packet forwarding rate: 1.19Mpps
Backplane bandwidth: 3.8Gbps, non-blocking design
Connection mode: Adaptive parallel line/cross line
Operating voltage: 12~52VDC flexible power supply
Protection level: IP50
Installation method: DIN35 rail-mounted installation
Operating temperature: -40℃~+85℃
Operating humidity: 5%~90%
