Order Number: M12D-FS-4P-PG7
Specification Description: M12 connector, straight pin, screw connection, D-Code
Voltage: 250V DC
Current: 4A
Shell Material: TPU/Black
Locking Nut: Alloy Copper/Gold Plated
Pin Holder Material: TPU + GF/Black
Contact Material: Brass/Gold Plated
Sealing Ring: FPM/FKM
Protection Grade: IP67 (after insertion and tightening) for M12
Wire Cross-sectional Area: 0.14...0.75mm²
Cable Diameter: φ4.0...8.0mm
Pollution Level: 3
Operating Temperature Range: -40℃...+85℃
Torque: ≥100
Insertion and Ejection Life: 0.6Nm (for M12 plug-type connector)
Application Scenario: Used for Ethernet communication conversion at M12 interface
