Order Number: M12D-MS-4P-PG9
Specification Description: M12 connector, straight pin, screw connection, D-Code, all-metal
Voltage: 250V DC
Current: 4A
Shell Material: Alloy copper / nickel plated
Locking Nut: Alloy copper / nickel plated
Pin Holder Material: TPU + GF / black
Contact Material: Brass plated nickel
Sealing Ring: FPM / FKM
Protection Grade: IP67 (after insertion and tightening) for M12
Wire Cross-sectional Area: 0.14...0.75mm²
Cable Diameter: φ4.0...8.0mm
Pollution Grade: 3
Operating Temperature Range: -40℃...+85℃
Torque: ≥100
Insertion and Ejection Life: 0.6Nm (for M12 plug-type connector)
Application Scenario: For Ethernet communication with M12 interface
