Order Number: M8-MS-3P
Specification Description: M8 connector, straight pin, screw wiring, A-Code
Voltage: 60V DC
Current: 4A
Shell Material: TPU/Black
Locking Nut: Alloy Copper/Gold Plated
Pin Holder Material: TPU + GF/Black
Contact Material: Brass/Gold Plated
Sealing Ring: FPM/FKM
Protection Grade: IP67 (after insertion and tightening) M12
Insulation Resistance: ≥100MΩ
Contact Resistance: ≤5MΩ
Pollution Grade: 3
Operating Temperature Range: -25℃...+80℃
Torque: 0.4Nm (for M8 plug-type connector)
Insertion and Ejection Life: ≥100
Application Scenario: For single-channel I/O signal wiring at M8 interface
