Order Number: MR0032P-EP
Bus interface: 2xRJ45, supports cascading
Power interface: Module power supply: 3P European spring terminal; Load power supply: 4P European spring terminal
I/O terminal: 3-pin e-CON connector
Operating voltage: 24V DC(-15% to +20%)
Working current: 150mA
Communication protocol: EtherNet/IP
Communication rate: 100M(Max), adaptive
Addressing method: Set the IP address through the LAE_config software
Protection grade: IP50
Installation method: DIN35 rail mounting or mounting with holes punched on both sides of the ears
Operating temperature: -20℃ to +75℃
Digital output points: 32
Output type: Transistor /PNP
Load types: Resistive load, inductive load, lamp load
Rated voltage: 24VDC(-15% to +20%)
Maximum output current: 0.5A per channel
Insulation: 500V DC between output and internal communication
Port protection: Overvoltage, overcurrent protection, reverse current protection
