Order Number: MRMS1600P-PN
Bus Interface: 2xM12, D-code, supports cascading
Power Interface: Module power supply: 3P European spring terminals; Load power supply: 4P European spring terminals
I/O Terminals: 2x3PIN European plug-in spring terminals
Operating Voltage: 24V DC (-15% to +20%)
Operating Current: 150mA
Communication Protocol: PROFINET RT
Communication Rate: 100M (Maximum), adaptive
Addressing Method: Through PROFINET master station software
Protection Level: IP50
Installation Method: DIN35 rail installation or double-sided ear hole installation
Operating Temperature: -20℃ to +75℃
Digital input points: 16
Input type: PNP
Isolation method: Optical coupling isolation
Rated voltage: 24V DC (-15% to +20%)
Logic "1" signal: 11 to 30V
Logic "0" signal: 0 to 5V
Input filtering: Minimum 2ms
