Order Number: SRX-88DN-8TC-RTU
Communication Protocol: Modbus RTU
Communication Interface: 1xRS485, 2x5P European spring terminals, can be cascaded
Baud Rate (kbps): 2400, 4800, 19200, 38400, 57600, 115200
Addressing Method: Set through PROFINET master station software or by dip switch Protection level: IP20
Installation method: DIN35 rail installation
Operating temperature range: -20℃ to +75℃
Rated voltage: 24DC (-15% to +20%)
Digital input points: 8
Input type: NPN
Isolation method: Optical coupling isolation
Logic "1" signal: 11~30V
Logic "0" signal: 0~5V
Input filtering: Latest 2ms
Digital output points: 8
Output type: NPN
Load type: Resistive load, inductive load, lamp load
Maximum output current: 0.5A per channel
Insulation: 500VDC between output and internal communication
Port protection: Overvoltage, overcurrent protection, reverse current protection
Number of thermocouple input channels: 8
Connection method: Two-wire system
Resolution: 16 bits (including sign bit)
Sensor type: K, S, R, B, J, N, E, T types of thermocouples
Temperature range: K type: -200 to +1300℃ S type: 0 to +1600℃ R type: 0 to +1600℃ B type: 100 to +1820℃ J type: -200 to -1200℃ N type: -270 to +1300℃ E type: -270 to 1000℃ T type: -200 to +350℃ Sampling error: ±0.5℃ (full scale)
Sampling rate: 500ms per time
Data output: 0.1℃ per digit
Software filtering: Configurable
